Automatic PVC & P.O shrink sealer
The machine is equipped with a conveyor that feeds packages to the welding and cutting stage automatically. Packages are received on the belt from another machine or belt (previous stage) or by the production worker.
• Speed / 15: 20 packs per minute. • Control through a 7-inch PLC touch screen. • Hook it up to raise and lower the slicer, according to the height of the product. • Side welding + cross cutter, to lock garnish tightly. • Roller assembled wrapping roll assembly, after welding process. • Air machine with feature (no product = no wrapper) empty bags from empty bags. • Specifiers to set product dimensions. • Emergency key. • Acrylic movable cover with shaded hydraulic hinges, in the welding area and won during work, personnel protection. • Maximum package dimensions / height 25 cm - width 40 cm - open length. • Maximum package weight / 20 kg. • Maximum roll width / 85 cm. • The machine body is coated with electrostatic paint. • Electricity consumption / 3 kilowatts. • Voltage / 380 volts. • Machine dimensions / length 2600 mm - width 1450 mm - height 1680 mm. • Machine weight: 400 kg.
• Speed / 15: 20 packs per minute. • Control through a 7-inch PLC touch screen. • Hook it up to raise and lower the slicer, according to the height of the product. • Side welding + cross cutter, to lock garnish tightly. • Roller assembled wrapping roll assembly, after welding process. • Air machine with feature (no product = no wrapper) empty bags from empty bags. • Specifiers to set product dimensions. • Emergency key. • Acrylic movable cover with shaded hydraulic hinges, in the welding area and won during work, personnel protection. • Maximum package dimensions / height 25 cm - width 40 cm - open length. • Maximum package weight / 20 kg. • Maximum roll width / 85 cm. • The machine body is coated with electrostatic paint. • Electricity consumption / 3 kilowatts. • Voltage / 380 volts. • Machine dimensions / length 2600 mm - width 1450 mm - height 1680 mm. • Machine weight: 400 kg.
